Hand Held Welding: OEM & Customization

Klear Laser customizes chassis using aerospace-grade aluminum for lightweight mobility and durability. Integrated cooling systems maintain optimal operating temperatures during continuous industrial use. Ergonomic designs reduce operator fatigue in demanding production environments.

Our software enables precise parameter adjustments tailored to specific materials and thicknesses. Real-time monitoring dynamically adjusts laser output for consistent weld quality. Seamless CAD/CAM integration ensures direct translation of design files to weld paths with minimal setup time.

We offer JPT and Raycus laser sources from 500W to 2000W for versatile industrial applications. Wobble welding heads adjust seam width and penetration depth on-the-fly. Custom power settings ensure optimal results for aluminum, steel, or high-strength alloys without distortion.

Principales características y ventajas

Klear Laser hand-held welders start with a JPT MOPA 1500-2000 W source that keeps the beam inside a 1.5 m·rad divergence envelope and gives you real-time power feedback through the CAN bus. That means every joint from 0.2 mm foil to 4 mm stainless sees the same energy density, so you do not have to waste time re-running parameters when you change material.

We pair the source with a patented wobble welding head built from aerospace-grade aluminum and water-cooled copper rails. A dual-axis galvanometer oscillates the focal spot 0–5 mm at 0–300 Hz while a 30 mm focal length Collimation keeps the beam waist inside the melt pool for 30 % deeper penetration and 40 % less porosity than a fixed optic. The head weighs 0.75 kg and carries an IP54-rated cover slide that you can swap in under 30 seconds on a dusty shop floor.

Because the head communicates with the source over EtherCAT, you can switch between spot, circle, and infinity weave patterns on the fly without touching the wire feeder. A built-in sensor locks out the trigger if the lens gets contaminated, so you never deliver a dirty beam to a critical stainless root pass.

Aplicaciones industriales

Hand-held fiber laser welding has revolutionized the automotive manufacturing landscape by replacing traditional TIG and MIG processes. Manufacturers utilize these systems for welding chassis components, exhaust systems, and intricate body panels where heat distortion must be minimized. The precise control offered by our wobble welding heads ensures deep penetration without compromising the structural integrity of thin-gauge metals.

In the aerospace sector, the demand for joining dissimilar metals and lightweight aluminum alloys is critical for flight efficiency. Klear Laser systems, powered by industry-leading JPT or Raycus laser sources, deliver the stability required for these high-stakes applications. Engineers rely on the high energy density of fiber lasers to create hermetic seals on sensors and fuel components that must withstand extreme atmospheric pressure.

Marine applications benefit significantly from the speed and cleanliness of handheld laser welding when fabricating stainless steel fittings and aluminum hull sections. The process eliminates the need for welding rods and fluxes, resulting in clean seams that are highly resistant to saltwater corrosion. This technology allows shipbuilders to achieve superior weld strength and aesthetic finish on deck equipment and structural supports.

The effectiveness of these applications relies heavily on the adjustable beam width provided by wobble welding head technology. By manipulating the beam path, operators can bridge wider gaps and ensure consistent fusion across variable joint geometries. This capability allows for deep penetration welding that rivals traditional methods while significantly reducing post-processing time.

Por qué elegir Klear Laser

Klear Laser provides an industry-leading 24-month comprehensive warranty on all core components, including critical JPT and Raycus laser sources. This extended coverage significantly reduces total cost of ownership by minimizing unexpected repair expenses during the machine’s most intensive operational phase. Our warranty explicitly covers wear items related to wobble welding heads and optical paths under normal industrial use. This commitment reflects confidence in the robustness of our fiber laser welding systems for demanding applications.

Global technical support operates 24/7 through regionally stationed engineers with direct factory escalation paths. Remote diagnostics resolve 85% of issues within four business hours, preventing extended production halts in welding operations. We provide on-site assistance within 72 hours for complex faults, ensuring minimal disruption to your welding throughput. This rapid response capability is critical for maintaining high-volume manufacturing schedules.

Spare parts availability is guaranteed through strategically located distribution hubs across North America, Europe, and Asia. Critical consumables and wear components—including proprietary wobble welding optics and laser delivery fibers—are shipped within 24 hours of order confirmation. Our extensive inventory ensures near-100% uptime for your handheld welding systems, directly supporting continuous production lines.
